Piscis GOLD 11.7hp Radial Compressor – Power and Efficiency for Intensive Systems
💨 Supplies up to 25.8 tons of biomass | 10.33 m³/min (620 m³/h) | Three-phase 220V/380V | Positive pressure: 400 mbar
Designed for high-demand systems, the Piscis GOLD 11.7hp Radial Compressor delivers high flow with continuous operation, making it ideal for oxygenation in intensive aquaculture systems and other applications that require reliable performance and long-term resistance.
Differentials that Guarantee High Performance:
✅ 24-hour operation – Industrial equipment for uninterrupted operation
✅ Weatherproof – Can be left outdoors, with protection against rain and sun
✅ Resistant finish with injected parts – High durability against heat, vibration and impacts
✅ UV protection and anti-corrosive paint – Ideal for external and humid environments
✅ Spare parts compatible with national standards – Practical and economical maintenance
✅ Customization for resellers – Colors and logos on request (check conditions)
Technical Specifications:
- Power: 11.7hp
- Flow rate: 10.33 m³/min (or 620 m³/h)
- Positive pressure: 400 mbar
- Suction pressure: -350 mbar
- Voltage: Three-phase 220V/380V
- Air outlet: 2 ½" or 75 mm
- Working position: Horizontal or vertical
- Weight: 65 kg
Oxygenation Capacity:
💧 Supplies up to 25.8 tons of biomass
(Based on: 20% O² dilution, 8% PV feed in feed, use of micro-perforated diffusers and total equipment yield. For help with sizing, consult our specialists.)
Warranty and Support:
🛡️ 3-month warranty against manufacturing defects
🔧 Up to 12 months warranty with the use of the Brasil Piscis Electrical Protection Panel
🔩 Spare parts ready for delivery, with specialized technical service
📞 Talk to our specialists for technical sizing or support:
📧 [email protected]
📱 WhatsApp: (11) 94704-8697
☎️ Landline: (11) 2021-5593
🌊 Piscis GOLD 11.7hp – robustness and continuous efficiency for large-scale oxygenation.
PERFORMANCE CURVE
The product performance curve is below to check if these can also meet your needs.
Positive pressure refers to the product pushing air, i.e., pulling air from outside and pushing it into the tank.
Negative pressure refers to the product pulling air, i.e., pulling air from inside a pipe, creating a vacuum in it.
.jpg)
Warranty
12-month warranty directly from the factory against manufacturing defects, not covering misuse or installation, electrical fault warranties only with the purchase of our protection and control panels.
No warranty for compressors that do not have an electrical protection panel.
