30m³ Rotary Drum – 110mm Outlet | 50mm Sewage | Automatic System with UV
High performance in filtration for water and effluent systems, with durability of up to 30 years.
The 30m³ Rotary Drum is a state-of-the-art equipment developed for the filtration and separation of solids in water, sewage and effluent treatment systems. Compact and efficient, it is ideal for aquaculture projects, industrial use and sustainable applications, offering an automated and highly efficient solution.
Made of stainless steel and polypropylene, this drum guarantees total resistance to corrosion, weather and direct sunlight — with an estimated durability of up to 30 years in outdoor environments.
Product Highlights:
✅ Premium structure: Made of stainless steel with polypropylene finish, resistant to chemicals and weathering.
✅ 100% Non-toxic: Safe for use with drinking water and systems that require sanitary control.
✅ Advanced filtration: Equipped with 70 micron stainless steel mesh, foams, filter media and UV lamp, promoting complete purification and elimination of microorganisms.
✅ Complete automation: Control panel and automated motor (40W in operation) ensure continuous and uniform rotation of the process.
✅ Practical maintenance: It has a cleaning nozzle, drainage gutter and integrated pump (45W) for cleaning, optimizing time and ensuring greater durability.
✅ High operating capacity: Ideal for tanks of up to 40,000 liters, with a maximum recommended flow rate of 30,000 liters per hour.
Technical specifications:
Passage capacity: up to 30,000 liters/hour
Recommended tanks: up to 40,000 liters
Voltage: 220V | 60Hz
Motor power (operation): 40W
Pump power (washing): 45W
Filtration: 70 micron stainless steel mesh + foams + filter media + UV
Inlet: 75mm
Main outlet: 110mm
Sewage outlet: 50mm
Dimensions: 70cm (L) x 53cm (W) x 57cm (H)
Material: Stainless steel and polypropylene
Warranty:
International: 2 years
Factory warranty: 1 year
Free replacement of defective parts under normal use
Ideal applications:
Aquaculture and intensive fish farming systems
Treatment of drinking water in remote or self-sufficient areas
Filtration of industrial or domestic effluents
Water reuse and sustainability projects
Cutting-edge technology for those seeking efficiency, safety and a long service life.
Contact us for technical support, installation or project consultancy.
📧 [email protected]
📞 (11) 94704-8697 | (11) 2021-5593
Warranty valid only for use under normal operating conditions.
